OnePlus 7T Pro McLaren Edition

Device overview

OnePlus 7T Pro McLaren Edition specifications

Explore the key features and detailed technical specifications available for the OnePlus 7T Pro McLaren Edition.

Documentation

User manuals

Manual details1 language

PDF

English manual

1.29 MB · 108 pages

Download PDF

PDF files are delivered through a protected Manual User Guide endpoint in a new tab.

CPU

Processor

Qualcomm Snapdragon 855 Plus

8 cores · 2960 MHz · Adreno 640

Processor details

Specifications

General

4 specifications

Device type

Smartphone

Release year

2019

Dimensions

162,6 x 75,9 x 8,8 mm

Weight

206 g

Specifications

Display and design

4 specifications

Main display

AMOLED 16M colors, 90 Hz, 1440 × 3120 pixels (6.67 inches) 515 ppi (pixels per inch)

Display details

od5do699

Screen-to-body ratio

88.5

Touchscreen

Yes

Specifications

Performance and memory

7 specifications

Processor

Qualcomm Snapdragon 855+

Clock speed

2,96 GHz

CPU cores

8

GPU

Adreno 640 @672 MHz

RAM

12 GB

RAM type

LPDDR4

Storage

256 GB

Specifications

Cameras and video

4 specifications

Main camera

48 Mpx, 8000x6000 px

Front camera

16 Mpx, 4608x3456 px

Flash

Yes, LED

Video recording

3840x2160 px, H.263, H.264, H.265, MPEG4 - 60 fps

Specifications

Battery and charging

4 specifications

Battery

Li-Ion 4085 mAh

Removable battery

No

Fast charging

Yes

Max charging power

30.0 W

Specifications

Networks and connectivity

22 specifications

Dual SIM

Yes

SIM type

Nano-SIM

2G bands

850/900/1800/1900

3G bands

850/900/1700/1900/2100

LTE bands

FDD LTE: 2600, 2300, 2100, 1900, 1800, 1700, 900, 850, 800, 700, 600TDD LTE: 2600, 2500, 2300, 2100, 1900

LTE

Yes

NFC

Yes

Wi‑Fi

Yes, v802.11 a/b/g/n/ac

Wi‑Fi bands

2.4 i 5 GHz

Wi‑Fi Direct

Yes

Wi‑Fi Display

Yes

Wi‑Fi hotspot

Yes

Bluetooth

Yes, v5.0

USB

Yes, v3.1 OTG Type-C

GPRS

Yes

EDGE

Yes

HSDPA

Yes, 42.20 Mbit/s

HSUPA

Yes, 11.52 Mbit/s

HSPA

Yes

HSPA+

Yes

WAP

Yes, v2.0

XHTML

Yes

Specifications

Calls and messaging

7 specifications

Dictionary

Yes, T9

MMS

Yes

Speakerphone

Yes

Voice dialing

Yes

Call forwarding

Yes

Email client

Yes

RSS reader

Yes

Specifications

Navigation and sensors

11 specifications

GPS

Yes

GLONASS

Yes

BeiDou

Yes

Galileo

Yes

Fingerprint reader

Yes

Accelerometer

Yes

Proximity sensor

Yes

Light sensor

Yes

Magnetometer

Yes

Gyroscope

Yes

Gravity sensor

Yes

Specifications

Software and multimedia

5 specifications

Operating system

Android 10

OS version

Android

Interface

OxygenOS 10

Audio player

Yes

Polyphony

Yes

Specifications

Organizer and accessibility

8 specifications

Java

Yes, ART

Calendar

Yes

Clock

Yes

Voice recorder

Yes

Alarm

Yes

Stopwatch

Yes

To-do list

Yes

Calculator

Yes

Specifications

Safety and commercial data

2 specifications

Head SAR

0.95 W/kg

Body SAR

0.90 W/kg
